TP-Link AC1900 Wireless Dual Band Gigabit Ceiling Mount Access Point EAP330 (US Version)
Grade A condition. Ceiling mount bracket is included (not shown in pictures).
Easily deploy a single unit to hundreds in minutes. Amazing range and speed. Heavy duty build. Product ships with Power supply (not commonly used if you use POE) and ceiling mount bracket. Retail packaging does NOT have a factory seal which is common in the EAP series. Central control software is available through TP-Link at no additional cost.
OVERVIEW
Speeds of up to 1.9Gbps over concurrent dual band 802.11ac Wi-Fi with MIMO and TurboQAM technologies
Airtime Fairness, Beamforming, and Band Steering Technologies guarantee optimal RF performance for business-level applications
Link aggregation joins two gigabit Ethernet ports to break the bottleneck in network backhaul capacity
FREE EAP Controller Software lets administrators easily manage hundreds of EAPs
Captive portal provides a convenient method for guest authentication
Power over Ethernet (802.3at) support and simple mounting design allow for flexible deployment and convenient installation
SPECIFICATIONS
HARDWARE FEATURES |
Interface |
Gigabit Ethernet (RJ-45) Port *2 (ETH1 Support IEEE802.3at PoE)
|
Physical Security Lock |
Kensington Lock Slot |
Button |
Reset |
Power Supply |
PoE or External 12VDC / 2.5A Power Supply |
Power Consumption |
US: 21.2 W |
Dimensions ( W x D x H ) |
8.7 x 7.6 x 1.4 in. (220.5*193.5*36.5mm) |
Antenna Type |
Internal Omni 2.4GHz: 3* 6dBi 5GHz: 3*7dBi
|
Mounting |
Ceiling /Wall Mounting (Kits included) |
Hardware Watch Dog |
Yes |
WIRELESS FEATURES |
Wireless Standards |
IEEE 802.11ac/n/g/b/a |
Frequency |
2.4GHz and 5GHz |
Signal Rate |
5GHz:Up to 1300Mbps 2.4GHz:Up to 600Mbps
|
Transmit Power |
< 27dBm |
Wireless Functions |
Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) Airtime Fairness Beamforming Band Steering Load Balance Rate Limit Link Aggregation Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client
|
Wireless Security |
Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
|
MANAGEMENT |
Omada Cloud Access |
Yes |
Omada App |
Yes |
Omada Cloud Controller |
Yes |
Omada Controller Software |
Yes |
Email Alerts |
Yes |
LED ON/OFF Control |
Yes |
Management MAC Access Control |
Yes |
SNMP |
v1,v2c |
System Logging Local/Remote Syslog |
Local/Remote Syslog |
SSH |
Yes |
Web-based Management |
HTTP/HTTPS |
L3 Management |
Yes |
Multi-site Management |
Yes |
Management VLAN |
Yes |
OTHERS |
Certification |
CE, FCC, RoHS |
Package Contents |
AC1900 Wireless Dual Band Gigabit Access Point EAP330 Power Adapter Mounting Kits Installation Guide
|
System Requirements |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
