NVT NV-8PS42-PVD 8-Channel Power Video Distribution CCTV Video over Cat 5e/6

by NVT
$122.76
SKU rwk-NV-8PS42-PVD-used
When ordering from the US, parcels may be subject to import tax and duty charges, which the buyer is responsible to pay.
NVT NV-8PS42-PVD 8-Channel Power Supply StubEQ Receiver DA Hub Class 2 SELV
Tested and in working condition. Includes power cord. Overall condition 9/10



The NVT NV-8PS42-PVD Power Supply StubEQ Active Receiver Hub (8-Channel) provides Class 2 SELV 28 VAC power to 8 cameras while receiving video transmission and delivering P/T/Z telemetry, all over a single Cat5 cable per camera. It consolidates all CCTV system cabling using standard EIA/TIA 568B structured building wiring.
Supporting camera current loads up to 1Amp/channel, the active receiver hub featuresbuilt-in distribution amplifier with 2 video outputs per channel. When used with any passive NVT transceiver, the receiver hub allows transmission of full motion CCTV video at distances up to 1500' (460m). The distance can be extended up to 2000' (600m) when used in conjunction with an NV-653T Active Transmitter.

Features:
  • 8-channel
  • Provides Class 2 SELV 28 VAC power to 8 cameras while receiving video transmission and delivering P/T/Z telemetry all over a single Cat5 cable per camera
  • Consolidates all CCTV system cabling using standard EIA/TIA 568B structured building wiring
  • Supports camera current loads up to 1Amp/channel
  • Built-in distribution amplifier with 2 video outputs per channel
  • Adaptive StubEQ fully automatic 2-band equalization provides adjustment-free equalization
  • When used with any passive NVT transceiver, the receiver hub allows transmission of full motion CCTV video at distances up to 1500' (460m)
  • Supports up to 2000' (600m) when used in conjunction with NV-653T Active Transmitter
Number of LAN Ports 8
Network Connectivity Wired-Ethernet (RJ-45)
MPN NV-8PS42-PVD
Brand NVT
Modified Item No
UPC 735890000846
Model NV-8PS42-PVD
Type Receiver Hub
