Marshall V-LCD12-TV-WM 12" LCD Surveillance Monitor/TV w/ Wall Mount PARTS ONLY

Sold out
Marshall V-LCD12-TV-WM 12" LCD Surveillance Monitor/TV w/ Wall Mount PARTS ONLY
Unit has been powered on and is confirmed to not work properly and so is being sold as PARTS ONLY. Comes as pictured; buy as-is.


The Marshall V-LCD12TVWM is a 12.1-inch Active Matrix LCD display, capable of displaying a full color 800x600 resolution in SVGA or analog video. The display allows the user to increase their available desktop real estate, by mounting the display on the wall with the supplied bracket.


The V-LCD12-TV can be used almost everywhere in the world because it is both NTSC and PAL systems compatible. The TV tuner though is only capable of displaying 125 NTSC channels.
The compact V-LCD12-TV has 18-bit color reproduction with 800 x 600 pixel resolution. This model has bright displays for installation in well-lighted exhibition areas, on the newscast set, or even outdoors.
System integrators choose this model for durability and installation flexibility since this unit can be factory or field configured for desktop, ceiling mounted, or wall mounted applications.
The monitor is ready for use as a computer display, video display or television right out of the box. There is a pair of quality speakers built into the monitor housing.


Application Computer and Video Display, Television Wall Mount
LCD Size 12.1" Diagonal
Video System NTSC and PAL
NTSC Channels 1-125 Only
Picture Elements 800 Horizontal x 600 Vertical Dots
Input And Output Connectors Composite Video- RCA (x 1 input only)
S-Video- 4-Pin (x 1 input only)
Audio- RCA (x 2 input only)
Computer- 15-Pin (x 1)
RF- Coaxial (x 1 input)
Picture Controls Contrast
Power Requirements 12 Volts DC
Power Consumption 3.5 Amp
Dimensions (W x H x D) 11.5 x 8.75 x 1.25 Iches (292.1 x 222.25 x 31.75 mm)
Weight 9.9 lb (4.5 kg)
