Cisco WS-C3750G-24TS-S1U 24-Port Gigabit Ethernet Switch Catalyst 3750G Series

Product Information

The Cisco Catalyst 3750G-24TS switch is a member of the Cisco Catalyst 3750 Series, an innovative product line that improves LAN operating efficiency by combining industry-leading ease of use and the highest resiliency available for stackable switches. This new product series represents the next generation in desktop switches, and features Cisco StackWise technology, a 32-Gbps stack interconnect that allows customers to build a unified, highly resilient switching system - one switch at a time.Using a 32-Gbps stack interconnect, Cisco StackWise technology is designed to respond to network changes of all kinds while maintaining constant high network performance. Cisco StackWise technology unites up to nine Catalyst 3750 switches into a single logical unit via special stack interconnect cables. The stack behaves as a single unit managed by a master switch elected from one of the member switches. Its advanced failover mechanisms create the highest levels of stackable resiliency for hardware and software reliability.

Product Identifiers

Brand

Cisco

MPN

WS-C3750G-24TSS1-U

UPC

4053162003057

Model

WSC3750G24TSS1U

eBay Product ID (ePID)

74096742

Product Key Features

Network Management Type

Fully Managed

Number of LAN Ports

24

Custom Bundle

No

Ethernet Technology

Fast Ethernet (100-Mbit/s)

Network Connectivity

Wired-Ethernet (RJ-45)

Dimensions

Weight

12.13lbs.

Width

17.5in.

Height

1.73in.

Depth

14.9in.

Additional Product Features

Interfaces

2X Network Stack Device, 1 X Management-Console-R&J Enterprises-45 Female, 24 X Network-Ethernet 10base-T/100base-Texas/1000base-T-R&J Enterprises-45 Female

Power Source

AC 120/230V (50/60Hz)

Networking Type

Switch

Ports Quantity

24

Power Consumption Operational

100W

Connectivity Technology

Wired

Routing Protocol

Rip-2, Hsrp, Rip-1, Static IP Routing, Ripng

Power Supply

Power Supply-Internal

Data Transfer Rate

1Gbps

Flash Memory

32MB Flash

Remote Management Protocol

Snmp 2C, Telnet, Rmon 9, Snmp 3, Tftp, Snmp 1, Rmon 2, Rmon 3, Rmon 1

Form Factor

Rack-Mountable

MAC Address Table Size

12k Entries

MAX Operating Temperature

113 ˚F

Type

Switch Managed Stackable

RAM Memory

128MB

Switching Protocol

Ethernet

Compatibility

PC

OTHER Features

Layer 3 switching, layer 2 switching, auto-sensing per device, DHCP support, auto-negotiation, ARP support, trunking, Cisco Fast EtherChannel, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), Cisco Gigabit EtherChannel , IGMP snooping, manageable, Rapid Spanning Tree Protocol (RSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS)

Humidity Range Operating (Range)

10-85%

Status Indicators

Port Status, Link Activity, Port Transmission SPEED, Port Duplex Mode, Status

Min Operating Temperature

32 ˚F

Enclosure Type

Rack-Mountable-1U

MAX. Data Transfer Rate

1000Mbps/1Gbps
