Cisco WS-C2960-24PC-L V02 Catalyst 24-Port Mangaged Network Switch 1Gbps

by Cisco
$44.00
SKU WS-C2960-24PC-L_USED
Cisco WS-C2960-24PC-L V02 Catalyst 24-Port Mangaged Network Switch 1Gbps
Grade B physical condition. Ships with universal power cable.

Product Information

Cisco Catalyst 2960 Series Intelligent Ethernet Switches are an easy solution to networking bottlenecks. Providing speedy Ethernet connectivity with a forwarding bandwidth of up to 16 Gbps, this switch is highly reliable and quick. The 24-port 10/100 Ethernet modules provide you with the ability to connect multiple routers, printers, and computers. These ports also support the use of voice over internet protocol phones. The Cisco Catalyst series PoE switch features Cisco IOS software. This software has a built-in LAN Base and LAN Lite applications. When you are ready to set up an internal communications system for your networked devices, these Cisco Catalyst series switches make the process efficient and simple. They have SmartOperations tools that simplify deployment. The installed flash memory allows you to collect data from the devices and use it for creating performance reports. The SmartOperations helps you to lower the cost per watt of Ethernet and maximize your investment. This rack-mountable ws-c2960-24pc-l series switch is easy to install. Each of its gigabit Ethernet ports has a LED indicator that glows green to show that it is operational. This Cisco Catalyst ws-c2960-24pc-l series switch has a built-in 370-watt PoE power supply. This power supply delivers 30 watts of power over Ethernet to each of the ports. The ports are also outfitted with SFP connectivity to work with older routers and equipment. The 2x1G dual purpose SFP allows you to move your router and devices as needed. The copper 1000 BASE-T and optical t/SFP Gigabit Ethernet uplink options allow you to expand your networks as your business grows. The Cisco Catalyst series switches are compliant with IEEE 802.3af for Power over Ethernet (PoE). The flexible authentication of this IEEE package enhances your network's security. This PoE switch also features a traffic monitoring mode, port security, and IP source guard. These options help to prevent an unauthorized access or request of your data. Its static IPV4 routing for conventional wired access networks provides you with multiple data protection layers. When new devices are connected to these Cisco Catalyst series switches, the product's zero-touch application automatically recognizes them. This fast deployment includes processes for configuring the switch interface and image. These features decrease the setup time for your equipment and allow the switch to function as a plug-and-play device. This Catalyst switch is also enabled with Cisco's EnergyWise program. The EnergyWise program allows the Catalyst to control the power consumed at each endpoint. It also powers down the switches during limited traffic conditions. This helps with both energy use totals as well as control of heat in large network systems. Enhanced security options ensure Cisco technology boosts networking performance. This type of network switch also keeps everything safe and secure using proprietary software that makes a network all but impossible to hack. Preventing prying eyes is just another way to keep customers happy, providing peace of mind to clients and network owners alike. Combining top quality hardware with the best software around, the 2960 is a smart choice for an expanding enterprise.

Product Identifiers

Brand
Cisco
MPN
WS-C2960-24PC-L
UPC
0882658169328
Model
WS-C2960-24PC-L
eBay Product ID (ePID)
74127699

Product Key Features

Number of LAN Ports
24
Custom Bundle
Yes
Network Connectivity
Wired-Ethernet (RJ-45)

Dimensions

Weight
12lbs.
Width
17.5in.
Height
1.73in.
Depth
13in.

Additional Product Features

Power over Ethernet (PoE)
Yes
Interfaces
2 Dual-Purpose (10/100/1000 or SFP) Ports
Network Management Type
Fully Managed
Power Source
AC 120/230V (50/60Hz)
Networking Type
Switch
Ports Quantity
24
Power Consumption Operational
433W
Connectivity Technology
Wired
Routing Protocol
Igmp
Power Supply
Power Supply-Internal
Data Transfer Rate
100Mbps
Flash Memory
32MB
Remote Management Protocol
Snmp 2, Rmon 9, Snmp 2C, Snmp 3, Tftp, Ssh, Https, Telnet, Ssh-2, Http, Rmon 2, Snmp 1, Rmon 3, Rmon 1
Form Factor
Rack-Mountable
MAC Address Table Size
8k Entries
MAX Operating Temperature
23 to 113 F
Type
Switch Managed
RAM Memory
64MB
Switching Protocol
Ethernet
OTHER Features
Layer 2 switching, auto-sensing per device, DHCP support, power over Ethernet (PoE), auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DHCP snooping, Quality of Service (QoS)
Compatibility
PC
Ethernet Technology
Ethernet
Humidity Range Operating (Range)
10% to 95%
Status Indicators
Link Activity, Port Transmission SPEED, Port Duplex Mode, Power, Link Oklahoma, System
Min Operating Temperature
23 F
Enclosure Type
Rack-Mountable-1U
MAX. Data Transfer Rate
1000Mbps/1Gbps
