Cisco ASA 5505 Series Adaptive Security Appliance ASA5505 V13 Firewalls

by Cisco
Sold out
$24.99
SKU ASA5505 V13_USED
Cisco ASA5505 V13 Adaptive Security Appliance ASA 5505 Series Firewalls
Grade A physical condition. May have some minor scuffs/scratches or stickers from previous installation. Units were pulled from a working environment and should be functional; regardless, power supply is NOT included and units are sold as-is. We do not know what the license is for this unit.


Your small offices or branch locations require the best network security available. An integrated solution that is easy to deploy and manage improves IT efficiency. Affordable pricing and the ability to scale as necessary are other important product benefits. You get all that and more with the Cisco®ASA 5505 Adaptive Security Appliance Firewalls. These firewalls are used and trusted by small and midsize businesses with one or a few locations.

Enterprise class security. Cisco MultiScale®performance, The ability to deliver multiple security services at scale. Unprecedented services flexibility. Modular scalability. Feature extensibility. Lower deployment and operational costs. All of these features and benefits add up to tremendous value in the Cisco ASA 5505 Adaptive Security Appliance. Available models deliver the same proven level of security that protects the networks of some of the largest and most security-conscious companies in the world.

Product Overview

The Cisco ASA 5505 is a full-featured firewall for small business, branch, and enterprise teleworker environments. It delivers high-performance firewall, SSL and IPsec VPN, and rich networking services in a modular, immediately operational appliance. Using the integrated graphical Cisco Adaptive Security Device Manager (ASDM), the Cisco ASA 5505 can be rapidly deployed and easily managed, helping businesses reduce operational costs. It features a flexible 8-port 10/100 Fast Ethernet switch whose ports can be dynamically grouped to create up to three separate VLANs for home, business, and Internet traffic for improved network segmentation and security.

The Cisco ASA 5505 provides two Power over Ethernet (PoE) ports, simplifying the deployment of Cisco IP phones with highly secure zero-touch voice over IP (VoIP) capabilities and the deployment of external wireless access points for extended network mobility. A high-performance intrusion prevention and worm mitigation service is available with the addition of the Advanced Inspection and Prevention Security Services Card (AIP SSC). Multiple USB ports can be used to implement additional services and capabilities, as needed.

As your business needs grow, you can install a Security Plus upgrade license, The Cisco ASA 5505 can then scale to support a higher site to site VPN connection capacity of 25 IPsec VPN connections, add full DMZ support, and integrate into switched network environments through VLAN trunking support. This upgrade license improves business continuity by helping to enable support for redundant ISP connections and stateless active/standby high-availability services.

Businesses can also extend the Cisco ASA 5505’s VPN service by enabling the Cisco AnyConnect client and clientless VPN remote access to support various mobile workers and business partners. Cisco secure remote access solution deployments can scale to serve up to 25 Cisco AnyConnect or clientless VPN concurrent users on each Cisco ASA 5505. Licenses for AnyConnect are purchased separately from the ASA based on feature tier (Plus/Apex) unique/authorized user count and term. The Apex tier also supports clientless SSL VPN connectivity. Additional information can be found in the AnyConnect ordering guide.

This combination of market-leading security and VPN services, advanced networking features, flexible remote management capabilities, and future extensibility makes the Cisco ASA 5505 an excellent choice for businesses requiring a best-in-class small business, branch, or enterprise teleworker security solution.

Table 1 lists the features and capacities of the Cisco ASA 5505 Adaptive Security Appliance for small offices and branch locations.

Table 1.       Cisco ASA 5505 Features

Feature

Cisco ASA 5505; Security Plus

Stateful inspection throughput (maximum1)

Up to 150 Mbps

IPS throughput2

Up to 75 Mbps with AIP‑SSC-5

Maximum 3DES/AES VPN Throughput3

Up to 100 Mbps

Users or nodes

Unlimited

Maximum Site-to-Site and IPsec IKEv1 Client VPN User Sessions3

10/25 (requires Security Plus license)

Maximum Cisco AnyConnect® or Clientless VPN User Sessions4

25 (Requires AnyConnect Plus/Apex license. Apex license required for clientless VPN)

Cisco Cloud Web Security users

25

Concurrent connections

10,000; 25,000*

New connections per
second

4000

Virtual interfaces (VLANs)

3 (trunking disabled)/
20 (trunking enabled)*

Security contexts (included/maximum)4

Not available

High availability

Not supported*

Expansion slot

1 SSC

USB 2.0 ports

3 (1 on front, 2 on rear)

Integrated I/O

8 Fast Ethernet with 2 PoE ports

Serial ports

1 RJ-45 console

Memory

512 MB

Minimum system flash

128 MB

System bus

Multibus architecture

Temperature

32 to 104°F (0 to 40°C)

Relative humidity

5 to 95 percent noncondensing

Altitude

Designed and tested for 0 to 9840 ft (3000 m); agency approved for 2000 m

Shock

1.14 m/sec (45 in./sec) 1/2 sine input

Vibration

0.41 Grms2 (3 to 500 Hz) random input

Acoustic noise

60 dBa max

Temperature

-13 to 158ºF (-25 to 70ºC)

Relative humidity

5 to 95 percent noncondensing

Altitude

0 to 15,000 ft (4570m)

Shock

30G

Vibration

0.41 Grms2 (3 to 500 Hz) random input

AC range line voltage

100 to 240 VAC

AC normal line voltage

100 to 240 VAC

AC current

1.8A

AC frequency

50/60 Hz

Dual-power supplies

None

DC domestic line voltage

See the ASA 5500 Series Hardware Installation Guide

DC international line voltage

See the ASA 5500 Series Hardware Installation Guide

DC current

See the ASA 5500 Series Hardware Installation Guide

Steady state

20W

Maximum peak

96W

Maximum heat dissipation

72 BTU/hr

Form factor

Desktop

Dimensions (HxW x D)

1.75 x 7.89 x 6.87 in. (4.45x 20.04 x 17.45 cm)

Weight (with AC power supply)

4.0 lb (1.8 kg)

Safety

UL 60950, CSA C22.2 No. 60950, EN 60950 IEC 60950, AS/NZS60950

Electromagnetic compatibility (EMC)

With DOE6 power supply: CE marking, FCC Part 15 Class A, AS/NZS CISPR22 Class A, VCCI Class A, EN55022 Class A, CISPR22 Class A

With DOE5 power supply: CE marking, FCC Part 15 Class B, AS/NZS CISPR22 Class B, VCCI Class B, EN55022 Class B, CISPR22 Class B

Industry certifications

FIPS 140-2 Level 2

In process: Common Criteria EAL4+ US DoD Application-Level Firewall for Medium-Robustness Environments, and Common Criteria EAL4 for IPsec/SSL VPN

1 Maximum throughput measured with UDP traffic under ideal conditions.
2 Firewall traffic that does not go through the IPS service can have higher throughput.
3 VPN throughput and maximum sessions depend on the ASA device configuration and VPN traffic patterns, including average packet size. These elements should be taken into consideration as part of your capacity planning. Throughput represents the maximum possible IPsec throughput. Maximum users may be further limited by your throughput requirements.
4 AnyConnect licenses required. See the AnyConnect Ordering Guide for details. Maximum users may be further limited by your throughput requirements.


Specifications
Dimensions (H x W x D):
1.75 x 7.89 x 6.87 inches (4.45 x 20.04 x 17.45 cm)
Serial ports:
1 RJ-45 console
Non-Operating Relative Humidity:
5 to 95 percent noncondensing
Integrated I/O:
8-port FE with 2 Power over Ethernet (PoE) ports
Memory:
512 MB
Operating Relative Humidity:
5 to 95 percent noncondensing
Non-Operating Altitude:
0 to 15,000 ft (4572m)
Dual power supplies:
Not available
High-availability support:
Stateless A/S only
Concurrent connections:
10,000; 25,000
Cisco Cloud Web Security users:
6
Non-Operating Vibration:
0.41 Grms2 (3 to 500 Hz) random input
Operating Shock:
1.14 m/sec (45 in./sec) 1/2 sine input
Operating Acoustic Noise:
60 dBa max
Integrated ports:
8 port 10/100 switch with 2 Power over Ethernet ports
Input (per power supply) AC Range line voltage:
100 to 240 VAC
Maximum 3DES/AES VPN throughput:
100 Mbps
Maximum site-to-site and IPsec IKEv1 client VPN user sessions:
10/25
Input (per power supply) AC Normal line voltage:
100 to 240 VAC
Operating Altitude:
Designed and tested for 0 to 9840 ft (3000 m); agency approved for 2000 m
Maximum Cisco AnyConnect IKEv2 remote access VPN or clientless VPN user sessions:
25
Input (per power supply) AC Frequency:
50/60 Hz
USB 2.0 ports:
3 (1 front, 2 rear)
Form factor:
Desktop
Non-Operating Temperature:
-13 to 158 F (-25 to 70 C)
Output Steady State:
20W
Input (per power supply) Dual-power supplies:
None
Expansion slot:
1 SSC
System bus:
Multibus architecture
Packets per second (64 byte):
85000
Operating Vibration:
0.41 Grms2 (3 to 500 Hz) random input
Input (per power supply) AC Current:
1.8A
Weight:
4.0 lb (1.8 kg) with AC power supply
IPS throughput:
Up to 75 Mbps with AIP-SSC-5
VLANs:
3 (trunking disabled) / 20 (trunking enabled)
Maximum new connections per second:
5000
Operating Temperature :
32 to 104 F (0 to 40 C)
New connections per second:
4000
Expansion I/O:
Not available
Weight (with AC power supply):
4.0 lb (1.8 kg)
Stateful inspection throughput (max):
Up to 150 Mbps
Output Maximum Peak:
96W
Non-Operating Shock:
30G
Output heat dissipation:
72 BTU/hr
Minimum system flash:
128 MB
Power:
AC/DC
Maximum concurrent sessions:
10,000 / 25,000
